Category Barometric Pressure : 3 products


Model 61205V

Barometric Pressure sensor

The Model 61205V Barometric Pressure Sensor is a versatile electronic barometer featuring high accuracy, low power, wide operating temperature range and calibrated voltage outputs. Low power consumption and wide temperature range make the 61205V ideal for remote applications using battery or solar power. The accuracy, which is better than 0.5 hPa (mbar), is maintained over the entire pressure and temperature ranges. Standard pressure scale for analog outputs spans 600 to 1100 hPa (mbar). Narrower ranges may be selected via software menu. The 61205V is designed for mounting in a weather proof enclosure. Mounting holes on the case allow for panel mounting with holes 1 inch on centre. The Model 61205V barometer requires no regular maintenance. Periodic calibration certification, if required, is available from the factory.

Download PDF
Brochure


[Pressure Range]   600 to 1100 hPa standard range
[Operating temperature]   -50 to +60C
[Accuracy]   0.5 hPa (mbar) at -50 to +60C
[Update rate]   2 seconds
[Analog Outputs]   0 to 2500 mV Standard range 600 to 1100 hPa (mbar) Other ranges user settable
[Analog Resolution]   0.1 hPa (mbar)
[Power]

7 to 30 VDC at 9 mA


Manufacturer R.M.Young

Model 61202V & 61202L

Barometric Pressure sensor

The New Model 61202 Barometric Pressure Sensor offers unparalleled performance and flexibility for atmospheric pressure measurement. The barometer is available in two configurations to satisfy a variety of applications; Model 61202V offers 0-5 VDC output, 61202L offers a 4-20 mA current output. Both models offer serial output in addition to the analog signal. The barometer is housed in a weatherproof molded case. Cable connections are inside. A U-bolt mounting is supplied for easy attachment to towers and masts. For outdoor installation, use of Model 61002 Pressure Port is recommended. The Pressure Port minimizes dynamic pressure errors due to wind.

Download PDF
Brochure


[Pressure Range]   600 to 1100 hPa standard range
[Digital resolution]   0.1 hPa
[Operating temperature]   -50 - +60 deg C
[Accuracy]   +-0.3 hPa at 20 deg C and 1 hPa at -50 to +60 deg C
[Update rate]   2 seconds
[Serial output]

Full duplex RS-232/

Half duplex RS-485/9600 baud/Polled or continuous/ASCII text output.

[Analog Outputs] 4.00 to 20.00 mA(61202L),  0-5VDC (61202V), standard range 600 to 1100 hPa, other range settable.
[Analog Resolution]   Depends on range / 0.1 hPa typical
[Power]   7 - 30 VDC at 30 mA
Manufacturer R.M.Young

Model 61002 Pressure port for barometric pressure sensor 61202.

For outdoor installation of Model 61202 Barometric Pressure Sensor, use of Model 61002 Pressure Port is recommended. The Pressure Port minimizes dynamic pressure errors due to wind.

Download PDF
Brochure


Manufacturer R.M.Young
